A digital top load tester for glass bottles is a specialized device used to measure the strength of glass bottles by subjecting them to vertical pressure. It features digital technology, including a digital display for accurate and easy-to-read test results.

  • Shipping Area: All over the world
  • Model: PCTLT-G500

ISO CE





The tester applies controlled force to the top of the bottle until it reaches its breaking point or a predetermined deformation limit. This test helps determine the bottle's structural integrity and ability to withstand external forces during handling, transportation, and storage. Industries such as beverages, pharmaceuticals, and cosmetics rely on digital top load testers to ensure the quality and safety of their products by verifying the bottles' strength and durability.

  • Load Capacity: 500 Kgf.
  • Compression Plates size: Ø180mm
  • Vertical Clearance: 500mm
  • Microprocessor based LCD load indicator.
  • Accuracy: ± 0.05% of load indicated.
  • Least Count: 0.05 Kgf
  • Chamber Construction: SS304
  • Motor: Crompton/ Bharat Bijlee make 1 hp Induction Motor with dedicated Gear Box
  • Drive: Crompton/Delta Make
  • Paint: Powder Coated & Hard Chromed
  • Power: 220V AC, 50Hz, Single Phase
  • Table top Model
  • Peak load hold Indication.
  • Operation for test from Machine with For, Rev and Stop switch on machine.
  • Results can be evaluated in Kgf.
  • Over load protection shall be provided.
  • Over travel protection provided
  • Complete enclosure of Glass Bottles
  • Heavy duty frame structure
×
